FEATURES:
- Designed for testing all types of 6V and 12V starter batteries, including lead-acid, gel, and AGM.
- Bad cell detection capability.
- Voltmeter mode for testing both the starter and the charging system.
- Anti-sparking clamps for safe operation.
- Back-lit display with 4 lines × 16 characters LCD for easy viewing.
- Ergonomic design with button layout and housing for one-handed operation.
- Starter system testing: pressing the down arrow displays the captured voltage from cranking the engine.
- Charging system testing: pressing the up arrow displays the captured high voltage from the alternator.
TECHNICAL DATA:
| Parameter | Specification |
|---|---|
| Detachable Test Lead | 100–1400 CCA |
| Screen Size | 50 cm / 2" |
| Voltmeter | 7.6 V – 17 V via battery clamp |
| Weight | 0.52 kg |
| Clamp Size | 90 mm |
| Multi-Languages Display | English, German, Italian, Portuguese |
| Display Dimensions | 76 × 39 mm |
